- Maximum Power : 440 Watts
- Number of Channels : 4
- RMS Power Output : 110x4 Watts
- Amplifier Class : D
- Fuse Rating : 25x2 A
Features:
- Switchable 2CH & 4CH input configuration
- Working status indicators: Power/Protection
- Gain input sensitivity clipping indicators
- Full range IR chipset digital circuit design
- DirectFET power mosfet output stage
- Compact size for easy installation
- SMD Technology on 4 layers FR4 PC Board
Specifications:
- RMS Power (1Ω): N/A
- RMS Power(2Ω): 110W x 4CH
- RMS Power (4Ω): 75W x 4CH
- RMS Bridge (stereo 4Ω): 220W x 2CH
- Max Power: 440W
- Power Supply: 12-14.4V
- Power Supply (Threshold): 8.4V-16.5V
- Idle Current: 0.66A
- Distortion - THD (1KHz@4Ω): <0.3%
- Distortion - S/N Ratio (A weight @ 1W): >90dB
- Distortion - S/N Ratio (A weight @ FP): -88dBA
- Input Sensitivity - Hi/Low Input Level: 0.3-8.5V
- Input Impedance - Low Input Level: 22Kohm
- Output Impedance: 2 Ohm
- Damping Factor (50Hz@4Ω): >100
- Bandwidth (-3dB): 20-30 kHz
- Crossover (-12 dB/ Oct) Variable High-Pass: 50Hz-500Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass: 50Hz-500Hz
- FUSE Ratings - ATC: 25Ax2
- Dimension - Length x Width x Height - Inches(mm): 7 Inches x 6.3 Inches x 1.9 Inches (179.5mm x 160mm x 48.3mm)
- UPC: 847169059094
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
