- Maximum Power : 600 Watts
- RMS Power Output : 600x1 Watts
- Amplifier Class : D
- Fuse Rating : 30x2 A
Features:
- Latest High-Efficiency Class D Topology
- Compact Size with Ambient backlit logo
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 Ch mode
- Proprietary Vega Bass Boost EQ Up To 12dB
Specifications:
- MAX Power Rating: 600W MAX
- RMS Power(2Ω): 1 x 600 W
- RMS Power (4Ω): 1 x 320 W
- Types: Class D
- Power Supply: Full PWM
- Power Supply (Threshold): 10.0DVC – 16.0DVC
- Idle Current: (0.7A)
- Distortion - THD (1KHz@4Ω): <0.1%
- Distortion - S/N Ratio (A weight @ 1W): -85dBA
- Distortion - S/N Ratio (A weight @ FP): -101.1dBA
- Input Sensitivity - Hi/Low Input Level: 1.1V ~>20.0V / 250mV – 6.0V
- Input Impedance - Low Input Level: 20 KΩ
- Input Impedance - High Input Level: 100 KΩ
- Output Impedance: 2 Ω
- Damping Factor (50Hz@4Ω): >70
- Bandwidth (-3dB): 10Hz-250Hz
- Crossover (-12 dB/ Oct) Variable High-Pass: N/A
- Crossover (-12 dB/ Oct) Variable Low-Pass: 35Hz-250Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: 10Hz-50Hz
- FUSE Ratings - ATC: 2 x 30A
- Dimension - Length x Width x Height - Inches(mm): 7.1 x 4.7 x 1.8 (180 x 120 x 46.5)
- UPC: 847169019739
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
