Phoenix Gold RX2 10s RX2 10" 200W Single 4-Ohm Subwoofer
We are a Phoenix Gold authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 25mm of Peak to Peak Excursion
- • Single 4-Ohms Voice Coil
- • High Excursion CAE/CAD Motor Design
- • KlaraForm Vented Kapton Former
- • UNICAP Technology
- • Phoeniroll Surround Technology
- • Torriform Voice Coil Technology
- • Nickel Plated 12 Gauge Speaker Terminal
- • Optimized for Sealed or Vented Enclosures
- • Powder Coated Anti-Resonant Steel Basket
RX2 10s Subwoofers
Features long wound 2.0” coils which allows for 25mm of peak to peak excursion. This results in an ability to create deep, accurate bass in vented or sealed enclosures.
- Diameter : 9.28 Inch
- Maximum Power : 200 Watts
- Sensitivity : 85.9 dB
- Impedance : 4 Ohm
- Peak Power Handling : 400 Watts
- Top Mount Depth : 5.25 Inches
- Shallow Mount : No
- Number of Voice Coils : Single
- Mounting Depth : 5.25 Inches
- RMS Power Handling : 200 Watts
- Free Air : 28Hz
Features:
- 25mm of Peak to Peak Excursion
- Single 4-Ohms Voice Coil
- High Excursion CAE/CAD Motor Design
- KlaraForm Vented Kapton Former technology reduces distortion by reducing heat and resistance
- UNICAP Technology provides a stiff piston for pronounced SPL
- Phoeniroll Surround Technology promotes linear motion
- Torriform Voice Coil Technology: Effectively dissipates heat and minimizes distortion
- Nickel Plated 12 Gauge Speaker Terminal
- Optimized for Sealed or Vented Enclosures
- Powder Coated Anti-Resonant Steel Basket
Specifications
- Subwoofer Series: RX2 Series
- Subwoofer Size: 10"
- Peak Power Handling: 400 watts
- RMS Power Handling: 200 watts
- Voice Coil(s): Single
- Impedance (Per Voice Coil): 4 ohms
Voice Coil Material
- Voice Coil Diameter: 2"
- Sensitivity: 85.9 dB
- Xmax (millimeters): 25 mm
- Subwoofer Design: Round / Circle
- Main Cone Color: Dark Gray
- Woofer Surround: Phoeniroll Surround Technology
- Recommended Enclosure Type: Ported / Vented / Sealed
- Optimum Sealed Box Volume: 0.5 cubic feet
- Optimum Ported Box Volume: 1.5 cubic feet
- Top-Mount Depth (Mounting Depth): 5.25"
- Cutout Diameter: 9.28"
- Shallow Mount Installation: No
- Free-Air Resonance (Fs): 28 Hz
- Equivalent Compliance (Vas): 35.93 liters
- Total Speaker Q Value (Qts): 0.33
- Electrical Q Value (Qes): 0.35
- Electrical Resistance of Voice Coil (Re): 3.4 ohms
- Mechanical Q Value (Qms): 6.6
- Parts Warranty Duration: 1 year
- Labor Warranty Duration: 1 year
- UPC: 609098827515
- Weight: 12
