We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
•One 13.5" Dual voice coil subwoofer (attached to an MDF baffle board with 12 Phillips-head screws)
•On-line product registration information
Taking the W7 design formula to its highest level
Words like "extreme," "reference" and "ultimate" get thrown around quite a bit in the subwoofer driver world, but rare is the product that can honestly lay claim to them. The 13W7AE does.
Taking the W7 design formula to its highest level, the 13W7AE offers a staggering linear excursion envelope that exceeds 1.25 inches (32 mm) one-way, along with a suspension capable of over 4-inches of peak-to-peak excursion. Combine that with a piston diameter that is 28% larger than the 12W7AE's, and you have a serious high-performance driver for the most demanding applications. With a 13W7AE, limits simply vanish and amazing sub-bass happens... on all fronts, at any level
Amplifier Power in the 500w - 1500w
JL Audio's most potent subwoofer driver is best used with amplifier power in the 500W - 1500W range and is optimized to operate in a 1.875 cu. ft. (53.1 l) sealed enclosure, or a 2.375 cu. ft. (67.3 l) ported enclosure.
Diameter : 13.5 Inch
Maximum Power : 3000 Watts
Sensitivity : 86.3 dB
Impedance : 1.5 Ohm
Frequency Response : 15-200 Hz
Peak Power Handling : 3000 Watts
Number of Voice Coils : Dual
RMS Power Handling : 1500 Watts
13.5" subwoofer with dual 1.5-ohm voice coils
polypropylene W-Cone with polyester foam surround
solid cast-alloy basket
power range: 500-1,500 watts RMS
peak power handling: 3,000 watts
frequency response: 15-200 Hz
sensitivity: 86.3 dB
top-mount depth: 10-1/2"
sealed box volume: 1.875 cubic feet
ported box volume: 2.375 cubic feet
Impedance (Ohms): 0.75, 3
Cone Material: Polypropylene
Surround Material: Polyester foam
Sensitivity: 86.3 dB at 1 watt
Frequency Response: 15 - 200 Hz
Max RMS Power Handling: 1500
Peak Power Handling (Watts): 3000
Top Mount Depth (inches): 10 9/16
Cutout Diameter or Length (inches): 12 1/8
Vas (liters): 104.3
Fs (Hz): 23.5
Xmax (millimeters): 32
Ideal Sealed Box Volume (cubic feet): 1.875
Ideal Ported Box Volume (cubic feet): 2.375
